ASUS ROG STRIX Z690-F GAMING WIFI

The ASUS ROG STRIX Z690-F GAMING WIFI is a premium motherboard designed for Intel CPUs, introduced in November 2021. It supports the latest technologies and features, making it ideal for high-performance gaming and computing setups.

Key specifications include:

• CPU Socket: Intel Socket 1700
• Chipset: Intel Z690
• Form Factor: ATX (30.5×24.4cm)
• Power Phase Design: 16+1 phases, with each phase capable of delivering 70A for Vcore

Memory support is robust:

• Memory Type: DDR5
• Maximum Speed: 6400MHz (PC5-51200)
• Slots: 4
• Maximum Capacity: 128GB
• Memory Channels: Dual
• Technologies: XMP and Optane support

For expansion, the motherboard offers:

• VGA Connection: PCIe 5.0 x16
• PCIe Slots: 2 x PCIe x16, 1 x PCIe x1
• PCIe Versions: PCIe 5.0, 4.0, and 3.0

Storage options include:

• M.2 Slots: 4 (supports PCIe 4.0, PCIe, NVMe, and SATA)
• SATA3 Ports: 6
• RAID Support: SATA RAID

Graphics outputs are versatile:

• HDMI and DisplayPort

The rear I/O panel is packed with connectivity options:

• USB3.x 20Gbps: 1 x Type C (rear)
• USB3.x 10Gbps: 1 x Type C (rear), 2 x Type A (rear)
• USB3.x 5Gbps: 4 x Type A (rear)
• USB 2.0: 2 x Type A (rear)
• Ethernet: 1 x RJ-45 (2.5Gbps, Intel I225-V)
• Audio: SupremeFX ALC4080, supporting 7.1 channel audio
• S/PDIF: Yes

Network and wireless capabilities:

• Wi-Fi
• Bluetooth

Additional features:

• Thunderbolt 4 Header
• USB3.0, USB2.0, and USB3.2 Type C Headers
• RGB and ARGB Headers: 1 x RGB 12V 4-pin, 3 x ARGB 5V 3-pin
• Fan Headers: 5 x 4-pin system fan
• TPM Header
• M.2 Heatsinks
• LED Lighting: AURA SYNC, with LEDs located on the front, logo, and I/O shield (armor)

The ASUS ROG STRIX Z690-F GAMING WIFI is engineered to deliver top-tier performance and reliability, featuring extensive connectivity, advanced cooling solutions, and stylish RGB lighting to enhance any gaming setup.
