The Micronics WIZMAX 1200W 80PLUS PLATINUM ATX 3.0 is a robust power supply unit (PSU) designed for high-performance computing systems. Released in February 2023, this PSU offers superior efficiency and reliability, making it an ideal choice for power-hungry applications and gaming rigs.

Key Specifications:

  • Rated Output: 1200W
  • Certification: 80 PLUS Platinum for high energy efficiency
  • Voltage Regulation: ±0.3%
  • Output: +12V single rail with 100% availability, 22A on +3.3V and +5V rails, 100A on +12V rail, 0.3A on -12V rail, and 3.0A on +5Vsb rail
  • Power Factor Correction (PFC): Active PFC with a 99% power factor

Cooling and Noise:

  • Fan: 120mm Fluid Dynamic Bearing (FDB) fan for quiet and efficient cooling
  • Fan Features: Fanless mode and automatic fan speed control for optimal cooling and noise management

Modularity and Connectors:

  • Design: Fully modular for easy cable management
  • Main Power: 24-pin (20+4)
  • Auxiliary Power: 8-pin (4+4) x 2
  • PCIe: 16-pin (12VHPWR) x 1, 8-pin (6+2) x 3
  • SATA: 12 connectors
  • IDE: 4 connectors
  • FDD: 1 connector
  • Cable Type: Flat cables for better airflow and neater builds

Additional Features:

  • Certifications: ETA Titanium and LAMBDA Standard++ for efficiency and noise
  • Protection Circuits: Comprehensive protection including OVP (Over Voltage Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), OPP (Over Power Protection), OTP/OHP (Over Temperature Protection), SCP (Short Circuit Protection), SIP (Surge & Inrush Protection), and NLO (No Load Operation)
  • Capacitors: High-quality 105°C capacitors for longevity
  • Design: DC to DC conversion and LLC resonant converter for stable and efficient power delivery
  • Standby Power: Less than 1W in standby mode
  • Voltage: Free voltage design to support global power standards

Warranty and Build Quality:

  • Warranty: 10 years of coverage for peace of mind
  • Build Quality: Compact design with a depth of 140mm, featuring premium components and solid construction

The Micronics WIZMAX 1200W 80PLUS PLATINUM ATX 3.0 is a top-tier power supply unit that combines high efficiency, robust protection features, and superior build quality, making it a perfect choice for building reliable and powerful computer systems.
